Angular JSON Configuration

Introduction

Angular CLI configuration file that defines how the Angular CLI builds, serves, and tests your application.

Why do we need it?

To customize build targets, file replacements, asset copying, and environment configurations without ejecting the build configuration.

Real-world analogy

Like a city’s master plan that outlines zoning, infrastructure, and building codes — angular.json defines how your Angular application is structured and built.

Visual Explanation

Mermaid Diagram

graph TD
    A[angular.json] --> B[Projects]
    B --> C[YourApp]
    C --> D[Architect]
    D --> E[Build]
    D --> F[Serve]
    D --> G[Test]
    E --> H[Options]
    H --> I[OutputPath: dist/your-app]
    H --> J[Index: src/index.html]
    H --> K[Main: src/main.ts]
    H --> L[Polyfills: src/polyfills.ts]
    H --> M[Assets: src/assets, src/favicon.ico]
    H --> N[Styles: src/styles.css]
    H --> O[Scripts: ]

Deep Explanation

The angular.json file is the central configuration for the Angular CLI. It defines:

Projects: Your Angular applications and libraries
Architect: Build targets like build, serve, test, lint, e2e
Configurations: Environment-specific settings (production, development)
File Replacements: Replace files for different environments (e.g., environment.ts)
Assets: Static files to copy to the output directory
Styles and Scripts: Global stylesheets and scripts
Budgets: Bundle size warnings and errors

Code Example

{
  "$schema": "./node_modules/@angular/cli/lib/config/schema.json",
  "version": 1,
  "newProjectRoot": "projects",
  "projects": {
    "your-app": {
      "projectType": "application",
      "schematics": {},
      "root": "",
      "sourceRoot": "src",
      "prefix": "app",
      "architect": {
        "build": {
          "builder": "@angular-devkit/build-angular:browser",
          "options": {
            "outputPath": "dist/your-app",
            "index": "src/index.html",
            "main": "src/main.ts",
            "polyfills": "src/polyfills.ts",
            "tsConfig": "tsconfig.app.json",
            "inlineStyleLanguage": "scss",
            "assets": [
              "src/favicon.ico",
              "src/assets"
            ],
            "styles": [
              "src/styles.scss"
            ],
            "scripts": []
          },
          "configurations": {
            "production": {
              "budgets": [
                {
                  "type": "initial",
                  "maximumWarning": "500kb",
                  "maximumError": "1mb"
                },
                {
                  "type": "anyComponentStyle",
                  "maximumWarning": "2kb",
                  "maximumError": "4kb"
                }
              ],
              "fileReplacements": [
                {
                  "replace": "src/environments/environment.ts",
                  "with": "src/environments/environment.prod.ts"
                }
              ],
              "outputHashing": "all"
            },
            "development": {
              "buildOptimizer": false,
              "optimization": false,
              "vendorChunk": true,
              "extractLicenses": false,
              "sourceMap": true,
              "namedChunks": true
            }
          }
        },
        "serve": {
          "builder": "@angular-devkit/build-angular:dev-server",
          "options": {
            "browserTarget": "your-app:build"
          },
          "configurations": {
            "production": {
              "browserTarget": "your-app:build:production"
            },
            "development": {
              "browserTarget": "your-app:build:development"
            }
          }
        },
        "extract-i18n": {
          "builder": "@angular-devkit/build-angular:extract-i18n",
          "options": {
            "browserTarget": "your-app:build"
          }
        },
        "test": {
          "builder": "@angular-devkit/build-angular:karma",
          "options": {
            "main": "src/test.ts",
            "polyfills": "src/polyfills.ts",
            "tsConfig": "tsconfig.spec.json",
            "karmaConfig": "karma.conf.js",
            "assets": [
              "src/favicon.ico",
              "src/assets"
            ],
            "styles": [
              "src/styles.css"
            ],
            "scripts": []
          }
        }
      }
    }
  },
  "defaultProject": "your-app"
}

Best Practices

Keep the configuration DRY by using extends for similar projects
Use configuration-specific file replacements for environment variables
Set up build budgets to monitor bundle sizes
Configure service workers for PWAs in the serviceWorker section
Use budget thresholds to catch regressions early

Common Mistakes

Forgetting to update the outputPath when changing project structure
Misconfigured asset paths leading to missing images/fonts
Overlooking the need to rebuild after changing angular.json
Incorrectly setting up proxies in serve configuration

Interview Questions

How would you configure multiple environments in angular.json?
What is the purpose of the “fileReplacements” section?
How do you add a third-party script to be loaded globally in your Angular app?

Summary

angular.json is the Angular CLI’s configuration file that controls how your application is built, served, and tested, allowing fine-tuning of the build process without ejecting from the CLI.
