Custom Directives

Introduction

While Angular provides many built-in directives like *ngIf, *ngFor, ngClass, and ngStyle, there are times when you need to create custom directives to encapsulate reusable DOM manipulation logic that isn’t covered by the built-in directives. Custom directives allow you to extend Angular’s template syntax with your own reusable components.

Why do we need this?

Built-in directives cover common use cases, but every application has unique requirements. Custom directives enable you to:

Encapsulate complex DOM manipulation logic
Create reusable behavior that can be applied across multiple components
Keep components focused on data and presentation logic rather than DOM manipulation
Share common UI patterns across your application without duplicating code

Real-world analogy

Think of custom directives as creating specialized tools for a workshop. While a standard toolset (built-in directives) covers most needs, sometimes you need a specialized jig or fixture (custom directive) for a specific task that you’ll use repeatedly across different projects. Once created, this tool can be shared with other craftsmen (developers) and applied to various workpieces (elements) as needed.

Visual Explanation

Mermaid Diagram

flowchart TD
    A[Custom Directive] --> B{Directive Type}
    B -->|Attribute| C[Modify Element Properties/Styles/Events]
    B -->|Structural| D[Create/Remove/Modify DOM Structure]
    C --> E[HostListener: Respond to Events]
    C --> F[HostBinding: Update Properties]
    C --> G[Input: Receive Configuration]
    D --> H[TemplateRef: Access Template]
    D --> I[ViewContainerRef: Create/Remove Views]
    D --> J[Input: Control Conditions]
    style A fill:#e3f2fd,stroke:#1890ff
    style B fill:#fff7e6,stroke:#fa8c16
    style C,D,E,F,G,H,I,J fill:#f6ffed,stroke:#52c41a

HostListener and HostBinding in Action

flowchart LR
    A[HostListener: mouseenter] --> B[Directive Method: onMouseEnter()]
    B --> C[Change Background Color]
    C --> D[Update UI]

    E[HostBinding: isHighlighted] --> F[Property Binding]
    F --> G[Element Property: class.highlighted]
    G --> H[Update CSS Class]

    I[Input: highlightColor] --> J[Directive Property]
    J --> K[Used in HostListener]

TemplateRef and ViewContainerRef in Structural Directives

flowchart TD
    A[Structural Directive: *appUnless] --> B[Input: Condition]
    B -->|False| C[ViewContainerRef.createEmbeddedView()]
    C --> D[TemplateRef: Create Embedded View]
    D --> E[Render Template in DOM]

    B -->|True| F[ViewContainerRef.clear()]
    F --> G[Remove View from Container]
    G --> H[Remove Template from DOM]

    I[ng-template #loadingTemplate] --> D
    I --> J[Template Reference]

Code Example

import { Component } from '@angular/core';

@Component({
  selector: 'app-custom-directives-example',
  template: `
    <div class="directives-demo">
      <h2>Custom Directives Demo</h2>

      <!-- Custom Attribute Directives -->
      <section>
        <h3>Custom Attribute Directives</h3>

        <!-- Tooltip Directive -->
        <div class="directive-section">
          <h4>Tooltip Directive</h4>
          <button appTooltip="This is a tooltip message!"
                  tooltipPosition="top"
                  tooltipClass="custom-tooltip">
            Hover over me
          </button>
          <button appTooltip="Another tooltip"
                  tooltipPosition="right">
            Tooltip on the right
          </button>
        </div>

        <!-- Highlight Directive -->
        <div class="directive-section">
          <h4>Enhanced Highlight Directive</h4>
          <input type="color" [(ngModel)]="highlightColor" placeholder="Highlight color">
          <input type="color" [(ngModel)]="defaultColor" placeholder="Default color">
          <p [appBetterHighlight]="highlightColor"
             [defaultColor]="defaultColor"
             (mouseEnter)="onMouseEnter()"
             (mouseLeave)="onMouseLeave()">
            Enhanced Highlight - Hover over me!
          </p>
          <p>Mouse enter count: {{ mouseEnterCount }}</p>
          <p>Mouse leave count: {{ mouseLeaveCount }}</p>
        </div>

        <!-- Scroll Spy Directive -->
        <div class="directive-section">
          <h4>Scroll Spy Directive</h4>
          <div appScrollSpy
               (scrollEvent)="onScroll($event)"
               [threshold]="200">
            <div class="scroll-content">
              <div *ngFor="let item of items" [class.active]="isActive(item.id)"
                   class="scroll-item" [id]="'item-' + item.id">
                <h3>Item {{ item.id }}</h3>
                <p>{{ item.content }}</p>
              </div>
            </div>
          </div>
          <div class="scroll-status">
            <p>Last scroll position: {{ scrollPosition }}px</p>
            <p>Currently viewing: {{ activeItem }}</p>
          </div>
        </div>
      </section>

      <!-- Custom Structural Directives -->
      <section>
        <h3>Custom Structural Directives</h3>

        <!-- Unless Directive -->
        <div class="directive-section">
          <h4>Unless Directive (opposite of *ngIf)</h4>
          <label>
            <input type="checkbox" [(ngModel)]="isLoading">
            Show Loading State
          </label>

          <p *appUnless="isLoading">
            Content is visible when NOT loading
          </p>

          <div *appUnless="isLoading; else loadingTemplate">
            <p>This content shows when isLoading is false</p>
            <button (click)="isLoading = true">Start Loading</button>
          </div>

          <ng-template #loadingTemplate>
            <div class="loading-indicator">
              <div class="spinner"></div>
              <p>Loading...</p>
            </div>
          </ng-template>
        </div>

        <!-- Repeat Directive -->
        <div class="directive-section">
          <h4>Repeat Directive</h4>
          <label>
            Repeat count:
            <input type="number" [(ngModel)]="repeatCount" min="1" max="10">
          </label>

          <div *appRepeat="repeatCount; let i = index">
            <div class="repeat-item">
              Item {{ i + 1 }} of {{ repeatCount }}
            </div>
          </div>
        </div>

        <!-- Unless with then/else -->
        <div class="directive-section">
          <h4>Unless with Then/Else Template</h4>
          <label>
            <input type="checkbox" [(ngModel)]="showError">
            Simulate Error State
          </label>

          <div *appUnless="showError; then successBlock else errorBlock"></div>

          <ng-template #successBlock>
            <div class="success-box">
              <h3>Success!</h3>
              <p>Everything is working correctly.</p>
            </div>
          </ng-template>

          <ng-template #errorBlock>
            <div class="error-box">
              <h3>Error Occurred</h3>
              <p>Something went wrong. Please try again later.</p>
              <button (click)="showError = false">Try Again</button>
            </div>
          </ng-template>
        </div>
      </section>
    </div>
  `,
  styles: [`
    .directives-demo { max-width: 800px; margin: 0 auto; padding: 20px; }
    .directive-section { margin: 30px 0; padding: 20px; border: 1px solid #eee; border-radius: 4px; }
    .directive-section h4 { margin-top: 0; color: #1890ff; }

    /* Tooltip Directive Styles */
    .tooltip {
      position: absolute;
      background: #333;
      color: white;
      padding: 5px 10px;
      border-radius: 3px;
      font-size: 12px;
      white-space: nowrap;
      z-index: 1000;
      pointer-events: none;
    }
    .tooltip-top { bottom: 125%; left: 50%; transform: translateX(-50%); }
    .tooltip-right { top: 50%; left: 125%; transform: translateY(-50%); }
    .tooltip-bottom { top: 125%; left: 50%; transform: translateX(-50%); }
    .tooltip-left { top: 50%; left: -125%; transform: translateY(-50%); }

    /* Tooltip Container */
    .tooltip-wrapper {
      position: relative;
      display: inline-block;
    }

    /* Highlight Directive */
    .highlight-box {
      padding: 15px;
      margin: 10px 0;
      min-height: 40px;
      transition: background-color 0.3s ease;
      text-align: center;
    }

    /* Scroll Spy */
    .scroll-spy-container {
      position: relative;
      height: 200px;
      overflow-y: auto;
      border: 1px solid #ddd;
      margin: 10px 0;
    }
    .scroll-content {
      padding: 10px;
    }
    .scroll-item {
      padding: 15px;
      margin: 10px 0;
      border-radius: 4px;
      transition: background-color 0.3s ease;
    }
    .scroll-item.active {
      background-color: #e3f2fd;
      border-left: 4px solid #1890ff;
    }
    .scroll-status {
      margin-top: 10px;
      padding: 10px;
      background-color: #f5f5f5;
      border-radius: 4px;
    }

    /* Unless Directive */
    .loading-indicator {
      text-align: center;
      padding: 20px;
    }
    .spinner {
      border: 4px solid #f3f3f3;
      border-top: 4px solid #1890ff;
      border-radius: 50%;
      width: 30px;
      height: 30px;
      animation: spin 1s linear infinite;
      margin: 0 auto 10px;
    }
    @keyframes spin {
      0% { transform: rotate(0deg); }
      100% { transform: rotate(360deg); }
    }

    /* Repeat Directive */
    .repeat-item {
      background-color: #f5f5f5;
      margin: 5px 0;
      padding: 10px;
      border-radius: 4px;
    }

    /* Unless with then/else */
    .success-box, .error-box {
      padding: 20px;
      border-radius: 4px;
      margin: 10px 0;
    }
    .success-box { background-color: #e8f5e8; border: 1px solid #4caf50; }
    .error-box { background-color: #fdecea; border: 1px solid #f44336; }
  `]
})
export class CustomDirectivesExampleComponent {
  // Tooltip demo
  // (no specific properties needed for basic tooltip)

  // Enhanced Highlight demo
  highlightColor = '#ffeb3b';
  defaultColor = '#f5f5f5';
  mouseEnterCount = 0;
  mouseLeaveCount = 0;

  onMouseEnter() {
    this.mouseEnterCount++;
  }

  onMouseLeave() {
    this.mouseLeaveCount++;
  }

  // Scroll Spy demo
  items = [
    { id: 1, content: 'First item content - Lorem ipsum dolor sit amet' },
    { id: 2, content: 'Second item content - Consectetur adipiscing elit' },
    { id: 3, content: 'Third item content - Sed do eiusmod tempor incididunt' },
    { id: 4, content: 'Fourth item content - Ut labore et dolore magna aliqua' },
    { id: 5, content: 'Fifth item content - Ut enim ad minim veniam' }
  ];

  scrollPosition = 0;
  activeItem = 'None';

  onScroll(event: any) {
    this.scrollPosition = event.scrollTop;
    // Determine which item is currently visible based on scroll position
    const itemIndex = Math.floor(event.scrollTop / 60); // Assuming 60px per item
    if (itemIndex >= 0 && itemIndex < this.items.length) {
      this.activeItem = `Item ${this.items[itemIndex].id}`;
    } else {
      this.activeItem = 'None';
    }
  }

  // Unless demo
  isLoading = false;
  showError = false;

  // Repeat demo
  repeatCount = 3;
}

// Tooltip Directive
import { Directive, ElementRef, HostListener, Input, OnInit, Renderer2 } from '@angular/core';

@Directive({
  selector: '[appTooltip]'
})
export class TooltipDirective implements OnInit {
  @Input() appTooltip: string = '';
  @Input() tooltipPosition: 'top' | 'right' | 'bottom' | 'left' = 'top';
  @Input() tooltipClass: string = '';

  private tooltipElement: any = null;

  constructor(private el: ElementRef, private renderer: Renderer2) {}

  ngOnInit(): void {
    if (!this.appTooltip) return;
  }

  @HostListener('mouseenter')
  onMouseEnter(): void {
    if (!this.appTooltip) return;
    this.showTooltip();
  }

  @HostListener('mouseleave')
  onMouseLeave(): void {
    this.hideTooltip();
  }

  private showTooltip(): void {
    this.tooltipElement = this.renderer.createElement('div');
    this.renderer.appendChild(this.tooltipElement, this.renderer.createText(this.appTooltip));

    // Add classes
    this.renderer.addClass(this.tooltipElement, 'tooltip');
    this.renderer.addClass(this.tooltipElement, `tooltip-${this.tooltipPosition}`);
    if (this.tooltipClass) {
      this.renderer.addClass(this.tooltipElement, this.tooltipClass);
    }

    // Append to body
    this.renderer.appendChild(document.body, this.tooltipElement);

    // Position tooltip
    this.positionTooltip();
  }

  private hideTooltip(): void {
    if (this.tooltipElement) {
      this.renderer.removeChild(document.body, this.tooltipElement);
      this.tooltipElement = null;
    }
  }

  private positionTooltip(): void {
    if (!this.tooltipElement) return;

    const hostElement = this.el.nativeElement;
    const hostRect = hostElement.getBoundingClientRect();
    const tooltipRect = this.tooltipElement.getBoundingClientRect();

    let top = 0;
    let left = 0;

    switch (this.tooltipPosition) {
      case 'top':
        top = hostRect.top - tooltipRect.height - 10;
        left = hostRect.left + (hostRect.width - tooltipRect.width) / 2;
        break;
      case 'right':
        top = hostRect.top + (hostRect.height - tooltipRect.height) / 2;
        left = hostRect.right + 10;
        break;
      case 'bottom':
        top = hostRect.bottom + 10;
        left = hostRect.left + (hostRect.width - tooltipRect.width) / 2;
        break;
      case 'left':
        top = hostRect.top + (hostRect.height - tooltipRect.height) / 2;
        left = hostRect.left - tooltipRect.width - 10;
        break;
    }

    // Adjust for scroll
    top += window.pageYOffset;
    left += window.pageXOffset;

    this.renderer.setStyle(this.tooltipElement, 'top', `${top}px`);
    this.renderer.setStyle(this.tooltipElement, 'left', `${left}px`);
  }
}

// Enhanced Highlight Directive
import { Directive, ElementRef, HostListener, Input, OnInit, Output, EventEmitter } from '@angular/core';

@Directive({
  selector: '[appBetterHighlight]'
})
export class BetterHighlightDirective implements OnInit {
  @Input() appBetterHighlight: string = 'yellow';
  @Input() defaultColor: string = 'transparent';
  @Output() mouseEnter = new EventEmitter<void>();
  @Output() mouseLeave = new EventEmitter<void>();

  constructor(private el: ElementRef) {}

  ngOnInit(): void {
    this.setBackground(this.defaultColor);
  }

  @HostListener('mouseenter')
  onMouseEnter(): void {
    this.mouseEnter.emit();
    this.setBackground(this.appBetterHighlight || 'yellow');
  }

  @HostListener('mouseleave')
  onMouseLeave(): void {
    this.mouseLeave.emit();
    this.setBackground(this.defaultColor);
  }

  private setBackground(color: string): void {
    this.el.nativeElement.style.backgroundColor = color;
  }
}

// Scroll Spy Directive
import { Directive, ElementRef, HostListener, Input, Output, EventEmitter } from '@angular/core';

@Directive({
  selector: '[appScrollSpy]'
})
export class ScrollSpyDirective {
  @Input() threshold: number = 0;
  @Output() scrollEvent = new EventEmitter<any>();

  constructor(private el: ElementRef) {}

  @HostListener('scroll', ['$event'])
  onScroll(event: any): void {
    this.scrollEvent.emit({
      scrollTop: event.target.scrollTop,
      scrollLeft: event.target.scrollLeft,
      scrollWidth: event.target.scrollWidth,
      scrollHeight: event.target.scrollHeight,
      target: event.target
    });
  }
}

// Unless Directive (opposite of *ngIf)
import { Directive, Input, TemplateRef, ViewContainerRef } from '@angular/core';

@Directive({
  selector: '[appUnless]'
})
export class UnlessDirective {
  @Input() set appUnless(condition: boolean) {
    if (!condition) {
      this.vcRef.createEmbeddedView(this.templateRef);
    } else {
      this.vcRef.clear();
    }
  }

  constructor(
    private templateRef: TemplateRef<any>,
    private vcRef: ViewContainerRef
  ) {}
}

// Repeat Directive
import { Directive, Input, TemplateRef, ViewContainerRef } from '@angular/core';

@Directive({
  selector: '[appRepeat]'
})
export class RepeatDirective {
  @Input() set appRepeat(count: number) {
    this.vcRef.clear();
    for (let i = 0; i < count; i++) {
      this.vcRef.createEmbeddedView(this.templateRef, {
        $implicit: i + 1,
        index: i
      });
    }
  }

  constructor(
    private templateRef: TemplateRef<any>,
    private vcRef: ViewContainerRef
  ) {}
}
